Specification
Alarm Interface
1 Input / 1 Output
Audio Interface
1 Input / 1 Output
Bit Rate
H.265: 14 ~ 9984Kbps / H.264: 24 ~ 10240Kbps
Bit Rate Control
Constant bit rate (CBR) / Variable bit rate (VBR)
Camera Type
Vehicle
Day/Night
Auto (IRC) / Colour / B&W
Dimensions
141 x 113 x 69mm
DORI Distance*
Detect: 56m
Observe: 22m
Recognise: 11m
Identify: 6m
Edge Storage
MicroSD Card (up to 128GB) / NAS / Local PC
Effective Pixels
2688 (H) x 1520 (V)
ePoE
No
Ethernet
RJ45 (10/100 Base-T)
Field of View
Horizontal: 104°, Vertical: 55°
Focus
Fixed
Frame Rate (Main)
4.0MP (1 ~ 25fps)
Frame Rate (Sub)
D1 (1 ~ 25fps)
Frame Rate (Third)
720p (1 ~ 25fps)
Gain Control
Auto / Manual
Housing
Metal
Image Sensor
1/3″ 4.0 Megapixel Progressive Scan CMOS
Infrared
Yes
Infrared System
2 x Infrared LED, 30m range, Auto/Manual on/off control
Ingress Protection
IP6K9K
Intelligent Functions
Face Detection, Tripwire, Intrusion, Abandoned/Missing Object, Motion Detection (4 Zone), Region of Interest (4 Zone), Privacy Masking (4 Zone)
Interoperability
ONVIF / PSIA / CGI
IVS
Yes
Lens / Iris
2.8mm F2.0 Fixed Lens
Lens Type
Fixed
Lighting Compensation
BLC / HLC / WDR (120dB)
Max. Resolution
4.0 Megapixel
Max. User Access
10 Users / 20 Users
Min Illumination
0.3 Lux at F2.0 (Colour) / 0 Lux at F2.0 (IR On)
Net Weight
0.59kg
Noise Reduction
3D DNR
Operating Conditions
-40° ~ +70° C / Less than 95% RH
Pan/Tilt/Rotation
N/A
Picture Control
N/A
Power Consumption
<6.5W
Power Supply
12VDC / PoE (802.3af)
Protocol
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP
RAM / ROM
512MB / 32MB
Resolution
4.0MP (2688 x 1520) to CIF (352 x 288)
RS485
N/A
S/N Ratio
> 50dB
Series
Mobile Series
Streaming Method
Unicast / Multicast
Tri-Axis Mounting
No
Ultra Low Light Colour
No
Vandal Resistance
IK10
Video Compression
H.265 / H.264
Video Interface
N/A
Weather Resistance
Yes
White Balance
Auto / Natural / Street Lamp / Outdoor / Manual
